Resistor Collection

Wasting time is such a waste (duh). Once you have modeled an object, it is great to have a library of part. The question is…how do you organize them in a way that you can find the part you need and easily import the part into you new design.

Today was my first attempt a building a library in Blender. I created a Blend file with 57 different configuration. There are 19 different resistance values (as indicated by the resistor color code) and each resistor is saved in 3 different mesh forms. The first form is straight. The 2nd form has both terminals bent at 90 degrees for horizontal mounting on a breadboard. The 3rd formation has one terminal bent to 180 degrees for vertical mounting on a breadboard. Continue reading
